Detects a Broader Range of Hand Gestures at Greater Distances, Ensuring Drivers’ Eyes Remain on the Road
MAX25405 next-generation optical sensor recognizes a variety of gestures in a quarter of the size and at 10x lower cost than camera-based time-of-flight systems in next-generation automotive, industrial and consumer applications
SAN JOSE, Calif. – June 29, 2021 – Maxim Integrated Products, Inc. (NASDAQ: MXIM) today introduced the next generation of its infrared-based dynamic optical sensor, able to sense a broader range of gestures at extended distances. The MAX25405 detects a wider proximity of movement and doubles the sensing range to 40cm when compared to earlier generations, all in a quarter of the size and at 10x lower cost than time-of-flight (ToF) camera-based systems in automotive, industrial and consumer applications. These enhancements offer an alternative to voice communications, enabling drivers to focus on the road.
For more information about Maxim Integrated’s MAX25405 gesture sensor, visit http://bit.ly/MAX25405Product
Get more information on all of Maxim Integrated’s sensor solutions at http://bit.ly/SensorPortfolio
Download a high-resolution image at https://www.maximintegrated.com/content/dam/images/newsroom/2021/max25405-pr.jpg
Along with integrated optics and a 6 x 10 infrared sensor array, the next-generation MAX25405 now includes a glass lens which increases sensitivity and improves the signal-to-noise ratio. The improved performance doubles the proximity and distance of sensing applications to beyond the driver, offering gesture-sensing entertainment displays to the co-driver and rear seat passengers, for example. The MAX25405 features a high level of integration compared to competitive ToF solutions that require three chips and a complicated microprocessor. The MAX25405’s small 20-pin, 4mm x 4mm x 1.35mm quad flat no-lead (QFN) package together with four discrete LEDs measures up to 75 percent smaller than ToF camera-based solutions.
Key Advantages
- Wide sensing range: The MAX25405 senses a wider proximity of movement and doubles the sensing range from 20cm to 40cm when compared to earlier infrared generations.
- Lowest cost and smallest size: The MAX25405 senses swipe, rotation and other important gestures at a lower cost than ToF cameras. High integration results in a total solution size that is significantly smaller than ToF camera solutions.
- Versatile: The MAX25405 recognizes nine gestures, including swipe, rotation, air-click, linger to click and 3 x 2 proximity zones with minimal lag time. This cost-effective single chip makes gesture-sensing affordable for multi-range automotive, consumer and industrial applications, including touch-free smart home hubs, thermostats and many more.
Commentary:
- “Maxim Integrated’s MAX25405 recognizes the most dynamic gestures at the lowest cost, allowing automakers to avoid the prohibitive cost of time-of-flight cameras and to help keep drivers’ eyes on the road,” said Szu-Kang Hsien, director for the Automotive Business Unit at Maxim Integrated. “The affordable gesture sensing feature adds value to low- and mid-range cars, while offering passengers the luxury of touch-free gesture control.”
Availability and Pricing
- The MAX25405 power management IC and associated MAX25405EVKIT# evaluation kit are available now from Maxim Integrated and authorized distributors; pricing available upon request.
